X Series Data Sheet
?
375, 500 Watt AC-DC and DC-DC DIN-Rail Converters
Part Number Description
L X N 2 660 -6 D2 F K2 G
Input voltage range ............................................................... L
Series ................................................................................... X
Nominal output power
375W ............................................................... R
500 W .............................................................. N
Number of outputs ........................................................... 1, 2
Type specification .................................................. 000 – 999
Operational ambient temperature range T A
–40 to 60 °C ................................................... -6
Customer-specific .................................... -0, -5
Options
Output voltage control input 2 ...................................... R
Save data signal 2 ......................................... D1, D2, D5
Multiple functions via D-SUB connector 2 ..... M1, M2
Built-in second fuse, input diode ..................... F
System connector ......................................... K2
RoHS compliant for all six substances ......... G 1
1
2
G is always placed at the end of the part number. Consult Power-One for availability !
Only one of these options is possible.
Note: The sequence of options must follow the order above.
NFND: Not for new designs.
Preferred for new designs
Example:
LXN2660-6D2FK2G: Power factor corrected AC-DC converter, operating input voltage range 85 – 264 VAC,
2 electrically isolated and individually regulated outputs, each providing 24.7 V, 10 A, options D2, F, K2, and RoHS-
compatible for all 6 substances.
Product Marking
Basic type designation, applicable safety approval and
recognition marks, CE mark, warnings, pin designation,
Power-One company logo.
Specific type designation, input voltage range, nominal output
voltages and currents, degree of protection, batch and serial
number, data code including production site, version, date of
production.
BCD20021-G Rev AC1, 13-May-2013
Page 3 of 21
www.power-one.com
